EAR Yoshino 324
5 106,00 €
EAR Yoshino 324 fono korektorius
The EAR 324 is the perfect solution for the vinyl-loving audiophile who demands the highest quality and the greatest flexibility. It features perfectly tailored inputs for both moving coil and moving magnet cartridges and offers accurate, low-noise amplification with vanishingly small signal degradation.
It has long been realised that amplifying the tiny signal from phono cartridges is one of the hardest jobs in electronics. Designer Tim de Paravicini has been devising elegant and efficient solutions to the problem over several decades, and the 324 represents the summary of his thinking. A fully transistorised product, it draws heavily on his acclaimed ”312 Control Centre” preamplifier in its circuitry but adds flexibility with switchable input impedance for both moving coil (MC) and moving magnet (MM) cartridges. Two separate inputs allow easy switching between two turntables (or two arms on one turntable), ideal for the serious collector who may have a separate deck and pickup for mono discs.
Tech spec
Input impedance:
switchable between 4 and 40 ohms (mc), 15k and 100k ohms (mm).
Output impedance:
60 ohms.
Gain:
54dB maximum.
Input sensitivity:
2.5mV (moving-magnet).
Signal/noise ratio:
68dB ref. 2.5mV input.
RIAA accuracy
0.3dB.
Channel balance:
0.2dB. THD: 0.2%.
Dimensions:
12.7″ W by 4″ H by 10.5″ D
Weight:
11 lbs.
