Pro-Ject RPM 5 Carbon Turntable
1 399,00 €
Pro-Ject RPM 5 Carbon is a manual belt-drive turntable for a carefully assembled stereo system. Its free-standing synchronous motor is designed to reduce vibration transfer to the low-resonance chassis. The 9-inch carbon-fibre tonearm is suitable for MM and MC phono cartridges. The turntable features an acrylic platter, an inverted bearing with a ceramic ball and adjustable aluminium feet.
Pro-Ject RPM 5 Carbon is a manual belt-drive turntable designed for a carefully assembled stereo system. It features a separate synchronous motor, an acrylic platter and a 9-inch carbon-fibre tonearm. The turntable supports 33 and 45 rpm speeds.
This is a fully manual model. You must place the record on the platter, lower the tonearm and lift it again after listening. Speed is also changed manually, making this turntable suitable for listeners who value fully manual operation.
Drive system and resonance control
The free-standing synchronous motor is isolated from the low-resonance chassis. This construction is intended to reduce the transmission of motor vibration to the chassis. The motor is controlled by an AC generator powered by a DC power supply.
The inverted main bearing uses a stainless-steel axle and ceramic ball. It supports the 300 mm acrylic platter.
Adjustable pointed aluminium feet allow the chassis to be levelled accurately while reducing its contact area with the supporting surface. Place the turntable on a stable, level and vibration-resistant surface.
Tonearm and cartridge selection
The fitted 9-inch 9cc EVO carbon-fibre tonearm has an effective mass of 8 g, placing it in the lightweight tonearm category. The tonearm is made from carbon fibre.
It is suitable for high-quality MM and MC phono cartridges. When selecting a cartridge, consider its weight, cantilever compliance and required tracking force. TPE damping in the counterweight is intended to reduce unwanted resonances.
The cartridge supplied with this store SKU is not specified. Before purchasing, confirm whether the turntable is supplied without a cartridge or with a particular cartridge model. This helps prevent an unnecessary duplicate cartridge purchase or an unplanned additional expense.
Connecting the turntable to a stereo system
The included Connect it E phono cable carries the audio signal. Connect the turntable to a phono preamplifier compatible with the selected cartridge type. You may also use an amplifier’s PHONO input if it supports the same MM or MC type.
A standard line-level AUX input cannot process the phono signal correctly. In that case, a separate phono preamplifier is required between the turntable and amplifier. Its MM or MC setting must match the cartridge being used.
Setup and operation
Before listening, level the turntable with its adjustable feet. Then set the tracking force according to the requirements of the selected cartridge. The available adjustment range is 0-25 mN.
The 33 and 45 rpm modes are selected manually. Use the correct speed for the record and stop the platter before changing speeds. The included 7-inch single adapter is intended for records with a large centre hole.
A record puck is included and helps the record rest securely against the acrylic platter. The dust cover is sold separately. Leave enough space for the motor, cable and comfortable tonearm operation.
Technical specifications
| Type | Manual belt-drive turntable |
|---|---|
| Motor | Free-standing 15 V AC synchronous motor |
| Motor control | AC generator powered by a DC power supply |
| Nominal speeds | 33 and 45 rpm; changed manually |
| Speed variance | ±0.12% at 33 rpm; ±0.10% at 45 rpm |
| Wow and flutter | ±0.17% at 33 rpm; ±0.08% at 45 rpm |
| Signal-to-noise ratio | 73 dB |
| Platter | 300 mm diameter, acrylic |
| Main bearing | Inverted, with stainless-steel axle and ceramic ball |
| Chassis | Low-resonance construction |
| Tonearm | 9-inch 9cc EVO, made from carbon fibre |
| Effective tonearm length | 230 mm |
| Effective tonearm mass | 8 g |
| Overhang | 18 mm |
| Tracking-force range | 0-25 mN |
| Cartridge types | MM and MC, subject to mechanical compatibility |
| Counterweight | With TPE resonance damping |
| Feet | Adjustable pointed aluminium feet |
| Maximum power consumption | 5 W |
| Standby power consumption | Less than 0.5 W |
| External power supply | 15 V DC / 500 mA |
| Mains supply | 110 or 240 V, 50 or 60 Hz |
| Dimensions | 430 × 150 × 323 mm (width × height × depth) |
| Weight | 8 kg |
| Finish options | Gloss red, gloss white or piano black |
| Manufacture | Hand-assembled in Europe |
| Cartridge supplied | Not specified; confirmation required before purchase |
| Included accessories | Connect it E phono cable, record puck and 7-inch single adapter |
| Dust cover | Sold separately |
FAQ
Is a phono cartridge included?
The cartridge configuration for this store SKU is not specified. Before purchasing, confirm whether the turntable is supplied without a cartridge or with a particular cartridge model.
How do I connect the turntable to an amplifier?
Connect it to a suitable PHONO input or a separate phono preamplifier. The phono stage must support the MM or MC cartridge being used.
Can the speed be changed with a button?
No. Switching between 33 and 45 rpm is performed manually after stopping the platter.
Where should I place the turntable?
Choose a rigid, level surface protected from vibration. Complete the final levelling adjustment with the aluminium feet.
Can I use a standard AUX input?
Only with a separate phono preamplifier. A direct AUX connection does not provide the amplification and frequency correction required for a phono cartridge.
Is a dust cover included?
No. The dust cover is sold separately. Keep this in mind if the turntable will be placed in a dusty or frequently used room.
