Eversolo DMP-A6 Master Edition Network Music Player
1 300,00 €
Eversolo DMP-A6 Master Edition is a network music player and DAC for a home stereo system. It brings music services, local files and external digital sources together in one device. Two ESS ES9038Q2M chips support PCM up to 768 kHz / 32-bit and DSD512. XLR and RCA outputs let you choose the appropriate analogue connection for your amplifier. The internal slot can accommodate an M.2 NVMe SSD of up to 2 TB.
Eversolo DMP-A6 Master Edition is a network music player, digital audio player and DAC for a home stereo system. It brings together online music services, a local music library and external digital sources.
Dual ESS ES9038Q2M DACs and an XMOS XU316 processor handle stereo PCM up to 768 kHz / 32-bit. DSD512 and MQA decoding are also supported. These limits apply to playback, DAC operation and the USB audio input.
Sources and network features
The player can connect to a home network through its gigabit RJ-45 Ethernet port or dual-band Wi-Fi. A wired connection is suitable for a permanent installation, while wireless networking reduces the number of cables required.
Available services and features include Tidal, Qobuz, Highresaudio, Amazon, Spotify, Tidal Connect and Qobuz Connect. AirPlay, DLNA, UPnP, WebDAV and Roon Ready are also supported. Service availability may depend on the software, region and service provider.
The Bluetooth 5.0 input accepts SBC, AAC, aptX, aptX Low Latency, aptX HD and LDAC signals. It provides a convenient way to start playing audio quickly from a compatible mobile device.
Digital connections
The USB-C audio input is intended for a computer or compatible mobile device. The stated compatibility includes Windows 7, Windows 10, macOS, Android and iOS.
The optical and coaxial inputs are suitable for a television, CD transport or another digital source. They support PCM up to 192 kHz / 24-bit and DSD64 via DoP. The optical and coaxial outputs have the same limits.
The HDMI audio output carries native DSD64 or unprocessed multichannel PCM up to 192 kHz. This is an audio output and is not intended to carry a video signal.
Analogue connections and control
The balanced XLR output is designed for an amplifier with XLR inputs. Its stated output level is 5.2 V. The unbalanced RCA output provides 2.6 V and is suitable for widely used analogue inputs.
When changing outputs, it is advisable to begin with the amplifier volume set low. The different output levels may produce an audible change in volume.
The 6-inch LCD touchscreen allows the player to be controlled directly at the unit. A mobile app provides control from the listening position.
Storage and placement
The internal M.2 NVMe 3.0 2280 SSD slot can accommodate a drive of up to 2 TB for a music library. An SSD is not listed among the supplied accessories, so its inclusion should be confirmed before purchase. Two USB-A 3.0 ports are provided for connecting USB devices.
The enclosure measures 187 mm deep, 270 mm wide and 90 mm high. Allow additional shelf space for the rear connections and cable bends. The player is suitable for a 110-240 V, 50/60 Hz mains supply.
Technical specifications
| Model | Eversolo DMP-A6 Master Edition |
|---|---|
| Device type | Network music player, digital audio player and DAC |
| Display | 6-inch LCD touchscreen |
| Internal memory | 4 GB DDR4 RAM and 32 GB eMMC |
| DAC chips | 2 × ESS ES9038Q2M |
| Audio processor | XMOS XU316 |
| Operational amplifier | OPA1612; distortion rating of 0.000015% at 1 kHz |
| Power-supply circuitry | Low-noise switching power supplies |
| SSD slot | M.2 NVMe 3.0 2280, up to 2 TB |
| USB-A ports | 2 × USB-A 3.0 |
| Ethernet | RJ-45, 10/100/1000 Mb/s |
| Wi-Fi | 2.4 GHz and 5 GHz |
| Playback and DAC | Stereo PCM up to 768 kHz / 32-bit, DSD512, MQA |
| Music services | Tidal, Qobuz, Highresaudio, Amazon |
| Network access | WebDAV, UPnP |
| Streaming | AirPlay, DLNA, Roon Ready, Spotify, Tidal Connect, Qobuz Connect |
| Bluetooth input | Bluetooth 5.0; SBC, AAC, aptX, aptX Low Latency, aptX HD, LDAC |
| USB-C audio input | PCM up to 768 kHz / 32-bit, DSD512, MQA |
| USB compatibility | Windows 7, Windows 10, macOS, Android, iOS |
| Optical and coaxial inputs | PCM up to 192 kHz / 24-bit, DSD64 via DoP, MQA |
| Optical and coaxial outputs | PCM up to 192 kHz / 24-bit, DSD64 via DoP, MQA |
| HDMI audio output | Native DSD64 and multichannel PCM up to 192 kHz, unprocessed signal output |
| Control | Mobile app and touchscreen |
| XLR output level | 5.2 V |
| XLR frequency response | 20 Hz-20 kHz, ±0.15 dB |
| XLR dynamic range | >128 dB |
| XLR signal-to-noise ratio | >128 dB |
| XLR THD+N | <0.00009% (-120 dB), A-weighted |
| XLR channel separation | >-125 dB |
| RCA output level | 2.6 V |
| RCA frequency response | 20 Hz-20 kHz, ±0.2 dB |
| RCA dynamic range | >124 dB |
| RCA signal-to-noise ratio | >124 dB |
| RCA THD+N | <0.00011% (-119 dB), A-weighted |
| RCA channel separation | >-124 dB |
| Power supply | 110-240 V, 50/60 Hz |
| Rated power | 13 W |
| Dimensions | 187 × 270 × 90 mm |
| Supplied accessories | Power cable, USB cable, screwdriver and user manual |
FAQ
What is this player designed for?
It is designed to manage network music, local files and external digital sources within a single home stereo system.
Which analogue output should I choose?
Choose XLR when your amplifier has balanced inputs. Use RCA with a conventional unbalanced analogue input.
When should I use USB-C rather than the optical input?
USB-C provides the highest stated PCM and DSD limits. The optical connection is convenient for a television or another source equipped with a compatible output.
Is an SSD already installed?
An SSD is not listed among the supplied accessories, so its inclusion should be confirmed before purchase.
Can the player be controlled remotely?
Yes. A mobile app is provided for everyday control, while the 6-inch touchscreen can be used directly at the player.
