2 independent stereo RCA Inputs
Weight: 4Kg
Dimensions: 220mm W | 80mm H | 260mm D
Subsonic filter: 10Hz/36dB octave
Frequency response: 20Hz – 20KHz
[Enhanced 20Hz – 50KHz] @ +/- 0.3dB
THD (Total Harmonic Distortion): <0.05% MAX
Signal to noise ratio: -89dB
Dynamic response: 105dB
Output impedance: 50Ω

AUDIO INPUTS

Input capacitance MM: 220pF
Input sensitivity: 0.1mV MC up to 7.0mV MM
Input impedance: 9 selectable options [10Ω, 22Ω, 47Ω, 100Ω, 220Ω, 470Ω, 1000Ω, 22KΩ, 47KΩ]
Gain: 65dB MC – 45dB MM with 4 options [-3dB, 0dB, +3dB, +6dB]

AUDIO OUTPUTS

Line output level (fixed): stereo RCA @ 2Volt and balanced XLR @ 4Volt

POWER

Main supply: 100V to 245V, 50/60Hz
(depending on market destination, not convertible)
Power consumption: 30W super linear power supply

UPGRADES

PSU-10 Dual-Mono External Inductive Power
