Pioneer DEH-1900UBA Car Stereo
Original price was: 90,00 €.75,00 €Current price is: 75,00 €.
The Pioneer DEH-1900UBA is a 1-DIN car stereo for drivers who use CDs, USB, AUX and FM or AM radio. Its USB port plays FLAC, MP3, WAV and WMA files, allowing music in several formats to be stored on one device. A five-band equaliser, frequency filters and a selectable-purpose RCA output help adapt the sound to the car’s audio system.
The Pioneer DEH-1900UBA car stereo is a 1-DIN in-car CD receiver for listening to music and radio. It suits drivers who want to use discs, USB storage or a separate audio source through AUX. Front-mounted connections make switching between sources convenient.
Music Sources and Connections
The built-in CD player reads CDs, CD-Rs and CD-RWs containing MP3 or WMA files. It displays CD Text and MP3 text, remembers the last playback position and includes a random-play mode.
The illuminated front USB port plays FLAC, MP3, WAV and WMA files. FLAC support is useful for listening to losslessly compressed music stored on a USB device. The front AUX input is intended for a device with an analogue audio output.
The phone features were designed for Android 4.1 and later versions available at the time. They provided music playback, control of selected phone applications and phone battery charging. Support for current Android versions and the Advanced Remote Control app has not been established.
Installation and Controls
The 1-DIN format is designed for a correspondingly sized car stereo slot. The front panel should remain easy to reach because it contains the USB and AUX connections.
The fully detachable faceplate can be removed from the main unit. The buttons have amber illumination. The wide-viewing-angle VA LCD presents up to 13 characters on one line. It supports Cyrillic characters, and its brightness can be adjusted through ten levels.
Audio System Adjustment
The five-band graphic equaliser lets you adjust different frequency ranges. It is sensible to begin with neutral settings, then alter individual bands while listening from the driver’s seat.
Advanced Sound Retriever processes the audio signal. Its effect is best evaluated by comparing playback with the function enabled and disabled when listening to compressed MP3 or WMA files. Source level adjustment helps reduce changes in volume when switching between radio, CD, USB and AUX.
The high-pass filter can limit the lowest frequencies sent to the main speakers. The low-pass filter shapes the frequency range used by the bass channel. Both filters should be adjusted for the connected speakers and the chosen system layout.
One RCA pre-out can be configured for either the rear channels or a subwoofer. This is a single configurable output, not two separate pairs. The system also includes Direct Sub Drive.
A maximum power figure of MOSFET 50 W × 4 is stated. The measurement method and conditions are not defined, so this figure should not be treated as a rated continuous-power value.
Radio Tuner
The FM and AM tuner includes RDS and 24 station presets. Automatic or manual frequency tuning can be used. Alternative-frequency search helps locate another frequency carrying the same programme.
Best Stations Memory stores the strongest stations. PTY search and RDS traffic announcements are also supported, allowing radio content to be selected by more than a specific frequency alone.
Technical Specifications
| Type | In-car CD receiver |
|---|---|
| Installation size | 1-DIN |
| CD media | CD, CD-R, CD-RW |
| CD file formats | MP3, WMA |
| CD features | CD Text, MP3 text display, last-position memory, random playback |
| USB port | Front, illuminated |
| USB file formats | FLAC, MP3, WAV, WMA |
| AUX input | Front |
| Radio bands | FM, AM |
| Radio features | RDS, automatic alternative-frequency search, automatic and manual tuning |
| Station features | 24 presets, Best Stations Memory, PTY search, traffic announcements |
| Graphic equaliser | 5-band |
| Audio processing | Advanced Sound Retriever |
| Filters | High-pass and low-pass filters |
| Audio-level control | Source level adjustment |
| Bass feature | Direct Sub Drive |
| RCA output | One, selectable for rear channels or a subwoofer |
| Maximum power figure | MOSFET 50 W × 4; measurement method not defined |
| Front panel | Fully detachable |
| Button illumination | Amber |
| Display | Wide-viewing-angle VA LCD, one 13-character line |
| Display brightness | 10 levels |
| Characters | Cyrillic characters supported |
| Original Android compatibility | Android 4.1 and later versions available at the time |
| Phone features | Control of selected phone applications, music playback, battery charging |
| Control app | Advanced Remote Control; current support has not been established |
FAQ
Who is this car stereo for?
It is intended for drivers who need a CD player, USB file playback, an AUX input and RDS radio. Current wireless phone connectivity is not specified.
When should I use USB, and when should I use AUX?
Choose USB for FLAC, MP3, WAV or WMA files stored on a USB device. Use AUX to connect a device with an analogue audio output.
Can the RCA output control the rear channels and a subwoofer at the same time?
No. The single RCA output is configured for one purpose: either the rear channels or a subwoofer.
Where should I begin when adjusting the sound?
Start with a neutral equaliser setting and balance the volume levels between sources. You can then adjust the filters to suit the connected speakers and system layout.
How can I check whether the stereo will fit my car?
Check that the vehicle has a 1-DIN installation slot and that the front USB and AUX connections will remain convenient to reach after installation.
Will the controls work with a current Android phone?
Original compatibility covered Android 4.1 and later versions available at the time. Support for the current app and modern operating systems has not been established.
