Falcon Acoustics IMF100 Speakers
1 700,00 €
Falcon Acoustics IMF100 is a pair of two-way bookshelf speakers for a home stereo system. A 1/8-wave folded transmission line fits a longer internal sound path inside the cabinet. Each speaker has a 5-inch driver with a Bextrene cone and a 19 mm tweeter with a Mylar dome. Single-wire terminals connect the pair to an amplifier’s speaker outputs.
Falcon Acoustics IMF100 speakers are a pair of two-way bookshelf speakers for a home stereo system. Each cabinet uses a 1/8-wave folded transmission line and contains a bass/midrange driver and a tweeter. The speakers connect to an amplifier through speaker cables and single-wire terminals.
Design and sound
The folded transmission line fits a longer internal sound path inside a bookshelf cabinet. The cabinet still needs room: it is 275 mm deep, and you will need additional space behind it for the connected cable.
The 5-inch bass/midrange driver has a Bextrene cone. A 19 mm tweeter with a Mylar dome handles high frequencies. You do not need to connect or adjust the two drivers separately.
The stated nominal frequency range includes a ±3 dB tolerance. That measurement condition helps explain the quoted range, but it does not define how the speakers will sound in your room. Where you place them, including their distance from the walls, will also affect the bass you hear.
Connecting your system
Single-wire terminals are fitted on the rear of each speaker. Connect each one to the speaker output of its corresponding amplifier channel. Connect your music source to the amplifier: the IMF100 terminals are designed to receive an amplifier’s speaker signal, not a direct connection from a phone or player.
The nominal 8 Ω impedance matters when choosing an amplifier. Its speaker outputs must be suitable for that load. The stated 86 dB sensitivity was measured at 2.83 V and a distance of 1 m. When comparing speakers, consider those measurement conditions as well as the sensitivity figure itself.
In a stereo system, connect the pair to the left and right channels. You can also use them with a home cinema receiver that has channel outputs intended for passive 8 Ω speakers. Choose the roles of the channels, any other speakers, and the receiver settings to suit your system.
Finding a place in the room
Allow a stable position on a shelf or suitable stands for cabinets that are 460 mm high and 225 mm wide. Each speaker weighs 12.5 kg, so its support must hold that weight securely. The cabinet dimensions do not include the extra room needed for a cable behind it.
Start with both speakers at roughly the same distance from your listening position. Then move them in small steps and listen from your usual seat. Bringing the cabinets closer to walls may change the amount of bass you hear in the room. These adjustments can help you find a position where the pair sounds balanced to you.
Choosing a finish
The IMF100 is offered in European walnut and Santos rosewood finishes. Choose the appearance that suits your room and other equipment. These finish names describe the offered appearance; they do not state that the entire cabinet is made from those materials.
Technical specifications
| Type | Two-way bookshelf speaker |
|---|---|
| Cabinet design | 1/8-wave folded transmission line |
| Bass/midrange driver | 5-inch, Bextrene cone |
| Tweeter | 19 mm, Mylar dome |
| Nominal frequency range | 38 Hz-20,000 Hz, ±3 dB |
| Nominal impedance | 8 Ω |
| Sensitivity | 86 dB at 2.83 V / 1 m |
| Connections | Single-wire terminals |
| Dimensions | 460 × 225 × 275 mm (height × width × depth) |
| Weight | 12.5 kg per speaker |
| Finish | European walnut or Santos rosewood |
| Sold as | Pair |
FAQ
What amplifier should I choose for this pair?
Choose an amplifier with speaker outputs suitable for an 8 Ω load. The sensitivity figure alone cannot tell you what amplifier power you need. The size of your room and how loudly you want to listen also matter when making that choice.
Can I use two cables for each speaker?
This model has terminals for single-wire connection. Each speaker uses one pair of cable conductors from its corresponding amplifier channel. There are no separate terminals for the different frequency bands.
Can I include these speakers in a home cinema system?
Yes, if your receiver has outputs intended for passive 8 Ω speakers. Each IMF100 uses one amplifier channel. Assign the channels and choose any other speakers according to the needs of your home cinema system.
Can I play music directly from my phone?
Connect the phone to an amplifier or another music source in your system. The IMF100 has terminals for speaker cable and receives its audio signal from an amplifier’s speaker outputs.
Do I need a subwoofer with this pair?
The stated frequency range begins at 38 Hz with a ±3 dB tolerance. Whether you want additional bass will depend on your room, the music you play, and your listening habits. That frequency limit alone does not settle the question.
How deep does my shelf need to be?
The cabinet is 275 mm deep. Leave extra space behind it for the connected cable and its bend. The shelf must also support the stated weight of the speaker securely.
Will my stands suit this pair?
Check that each stand can safely support a 12.5 kg speaker and provide a stable base for a 225 × 275 mm cabinet. The speaker is 460 mm high, so consider its total height when placed on the stand.
