Denon RCD-N11 DAB Network CD Receiver Amplifier

Denon RCD-N11 DAB is a network CD receiver with an integrated stereo amplifier. It is designed for playing CDs, network music and sound from a television. This is the main unit only, without speakers, so a pair of passive speakers must be purchased separately.

Who is this unit for?

This compact unit combines a CD player, network playback functions and a Class D stereo amplifier in a single enclosure. It is a practical choice for listeners who want to reduce the number of separate audio components in their system. The stated amplifier output is 65 W + 65 W into a 4-ohm load.

This figure cannot be compared directly with continuous power ratings measured under different conditions. The frequency range, distortion limit and channel-loading conditions used for the stated rating are not provided.

Wired audio connections

The optical digital input can be used to connect a television or another digital source. When the unit receives a compatible digital signal, it can switch on automatically and begin playing the sound. This helps reduce the number of steps needed during everyday television viewing.

High-resolution files can be played through the USB connection or over a local network. USB is a convenient option for music stored on removable media, while the network connection is better suited to accessing a music library held on a computer.

Wireless and network playback

Bluetooth lets you send audio from a phone, tablet or computer. AirPlay and AirPlay 2 provide playback from compatible Apple devices. AirPlay 2 can also synchronise music across multiple compatible devices or speakers.

AirPlay 2 requires iOS 11.4 or later. The receiver can also play internet radio and audio files stored on a computer connected to the network.

File formats and gapless playback

WAV, FLAC and ALAC files are supported at resolutions of up to 192 kHz / 24-bit. For DSD files, supported sampling rates are 2.8 and 5.6 MHz. Gapless playback is available for WAV, FLAC, ALAC and DSD recordings.

Gapless playback is particularly useful for live concerts, classical works and albums created as one continuous programme. It prevents an additional pause from being inserted during transitions between tracks.

Control and speaker settings

The HEOS app provides the main control functions on iPhone, iPad, Android and Amazon Kindle Fire devices. The mobile device and receiver must be connected to the same LAN or Wi-Fi network.

A selectable Speaker Optimization function adjusts the processing for the separately sold Denon SC-N10 speakers. This dedicated setting is specifically tailored to the SC-N10 model. Digital sources are processed within the digital circuit, while the circuit layout is designed to reduce unwanted signal interference.

Placement and system planning

Place the main unit on a stable surface and leave convenient access to the connections you intend to use. Choose the speaker positions according to the design of the selected speaker pair and your listening position. Denon SC-N10 speakers are not included.

Technical specifications

FAQ

Are speakers included?

No. This is the main RCD-N11 DAB unit and requires a separately purchased pair of passive speakers.

How do I connect a television?

Use the optical digital input. A compatible digital signal can switch the unit on automatically and start audio playback.

When should I use Bluetooth, and when should I use AirPlay 2?

Bluetooth is suitable for straightforward playback from a range of mobile devices. Choose AirPlay 2 when you want synchronised playback within a compatible Apple system.

Do I have to use Denon SC-N10 speakers?

No. However, the selectable Speaker Optimization setting is designed specifically for the separately sold SC-N10 speakers.

How do I start controlling the receiver with the HEOS app?

Connect the receiver and your mobile device to the same local network. Then select the RCD-N11 DAB in the app to access its main controls.
