TAD D1000TX

Model No.
TAD-D1000TX

Digital audio inputs

1 XLR, 2 coaxial, 1 optical, 1 USB (Type B)

Compatible sampling frequencies: XLR and coaxial inputs: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz

Optical input: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz

USB input^*: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz, 352.8 kHz, 384 kHz, DSD64 (2.8 MHz), DSD128 (5.6 MHz), DSD256 (11.2 MHz)

USB operating environment

USB 2.0 high-speed

Digital audio output

1 XLR, 1 coaxial

Analog audio output

1 balanced output

1 unbalanced output

Output voltage rated value

4 V balanced, 2 V unbalanced (1 kHz 0 dB)

S/N ratio

115 dB

Frequency characteristics

Sampling frequency 88.2 kHz and above: 10 Hz to 40 kHz -1 dB

Sampling frequency 44.1 kHz: 10 Hz to 20 kHz -1 dB

Power supply voltage

AC 120 V, 60 Hz (United States and Canada)

AC 220 V to 240 V, 50 Hz/60 Hz (Europe and Asia)

Power consumption

43 W

Power consumption during standby

0.5 W or less

Dimensions

440mm (W) x 150mm (H) x 406mm (D)

(17-11/32 in. (W) x 5-29/32 in. (H) x 16 in. (D))

Weight

18.5 kg

(40.8 lbs.)

* Compatible with Windows 8, Windows 7, Windows Vista, Mac OS 10.6 and higher, except PCM352.8 kHz, 384 kHz, DSD128, and DSD256, which are compatible with only Windows 10, Mac OS 10.6 and higher
