TAD C700
69 000,00 €
TAD C700 pradinis stiprintuvas
Model No.
TAD-C700
Rated output voltage
Balanced output 1.5 V, Unbalanced output 0.75 V
Maximum output voltage
Balanced output 20 Vims, Unbalanced output 10 Vrms
Input Impedance
Balanced input 100 kΩ, Unbalanced input 50 kΩ
S/N Ratio
120 dB
Frequency response
10 Hz‐100 kHz (-1 dB)
Input Terminals
Balanced input x 4, Unbalanced input x 2
Output Terminals
Balanced output x 2, Unbalanced output x 2
Power Supply Voltage
AC 120 V, 60 Hz (USA); AC 220 V to 240 V, 50 Hz/60 Hz (Europe, Asia)
Power Consumption
52 W (Power consumption during standby: 0.5 W or less)
Dimensions
Main amplifier unit: 450 mm (W) x 150 mm (H) x 440 mm (D) [17-23/32 in. (W)x 5-29/32 in. (H) x 17-21/64 in. (D)],
Power-supply unit: 220 mm (W) x 185 mm (H) x 430mm (D) [8-21/32 in. (W) x 7-9/32 in. (H) x 16-59/64 in. (D)]
Weight
Main amplifier unit: 29.0 kg (63 lb 15 oz),
Power-supply unit: 15.0 kg (33 lb 1 oz)
