Steg MSK 1500

Stereo amplifier HIGH-END 200 + 200 Watts RMS into 4 ohms, 1400 watts RMS into 1 ohm. conversion stage dc-dc differential (positive and negative branches separated) to energy recovery, mosfet switching for a total of 640 A, stabilized in P.R.H.E.S.S. technology (Primary Regulated High efficence Supply System) up to 11 Volt battery power. Stage amplifier configuration to „triple darlinghton” high yield sound developed on transistors 40 MHz Sanken, equipped with a complex of automatic biasing circuit. of the symmetric signal processor all along its path realized in BJT and FET transistors very low feedback.
Audiophile preamp that uses low-noise operational amplifiers as well as precision resistors and capacitors. Electronic Crossover excludable that uses high-precision AQXM2 frequency modules (settable in high-pass, low-pass and band-pass) with a slope of 12 dB / oct and Q @ configurable to 0.7 or 1 Tchebitchef Butterworth. Paragraphic continuously variable equalizer (0 / + 12dB – 40 / 120Hz). Levels of input sensitivity separated. Bypass output. Forced ventilation system in Termo-controlled load speed. GR.I.P.S. system immunization by the integrated electromagnetic interference. Operation Stereo / Mono simultaneous „Trimode”. automatic reset protection. Fixing system TRIMFEET sliding feet.

POWER:

Power 4 ohms stereoWatt RMS – 11 to 14.4 Volt 200 x 2
Power 2 ohms stereoWatt RMS – 11 to 14.4 Volt 400 x 2
Power 4 ohms monoWatt RMS – 11 to 14.4 Volt 800 x 1
Power 2 ohms monoWatt RMS – 11 to 14.4 volts 1500 x 1

SENSITIVITY ‘ENTRANCE:

Volts RMS 0.5 V – 5 V

DIMENSIONS:

420 x 60 x 255 mm

WEIGHT:

7.4 Kg
