The midrange is handled by two 5” drive units. They are placed in a MTM configuration to further lower distortion, lower crossover points and control the dispersion. The lower distortion and broadband performance will reveal every layer of music to you.
The massive crossover is placed in the bottom, and all acoustical treatment inside the TD3.8 is carefully measured and matched for absolute performance. The crossovers them selves are pieces of art, that deserves the day of light.
The TD3.8 is the one to beat in this class. The power and magnitude is equally matched with timing, phase and coherency in a full-range design that is musically authentic, real and extremely convincing. Audition the TD3.8 and discover what you have been missing…
Raidho Series TD
Drive Unit
This is truly a unique and revolutionary drive unit! 100% developed and build inhouse by Raidho. The goals was simple: no coloration and outstanding dynamic capabilities.
The motor comprises of a very strong magnet (N52 Neodymium) with an unseen even magnet field, coupled with an underhung titanium voice coil. This arrangement gives the drive unit the most powerful underhung magnet system in the world. The benetfit from an underhung voicie coil over the traditional overhung, is that it is much more linear and better dynamic capabilities. The result is perfect transient response with no measurable distortion.
The Legendary Raidho Ribbon Tweeter
Our proprietary, trademark ribbon tweeter is a unique design. It is completely designed and build by hand in-house in Denmark. To be exact, it is a Planar Magnetic Tweeter due to the tracks in the foil. The foil is 11 micron thick, which means it is 50 times less mass in comparison to a conventional dome tweeter. This is because there is no voice coil and the extreme low weight of the foil (20 milligram). The result is virtually no resonances or distortion, and the breakup point is at an incredible 82 KHz! What you hear is amazing clear and natural sound. All the detail in the world, but no fatigue, no distortion, and no coloration!
Bass Loading – Bass reflex Port in rear, Impulse optimized – Conform
Drivers
1 x Raidho TD Ribbon Tweeter
2 x 5” Raidho Tantalum Diamond midrange
2 x 8” Raidho Tantalum Diamond bass
Crossover Point – 400Hz and 2.4 kHz stepped slope
Frequency Range – 24Hz-50kHz+/-3d
Sensitivity – 89dB 2,83 V/m
Nominal Impedance – 6 Ohm
Power Requirement – 50 -300 Watts
Dimensions WxHxD, mm – 440x1420x620 including feet
Enclosure WxD, mm – 250 x 620
